2000L Cosmetic Making Machine Laundry Detergent Dish Soap Vacuum Homogenizing Emulsifying Mixer
Family Daily Toiletries products Making Machine Laundry Detergent Dish Soap Vacuum
Homogenizing Emulsifying Mixer
Techanical Parameter of theVacuum Homogenizing Emulsifying Mixer:
| Technical Parameters | ||||||
| Model | Volume(L) | Emulsify Mixer Tank | Size(L×W×H) | |||
| Emulsify motor(KW) | Emulsify speed(RPM) | Scraped wall motor(KW) | Scraped wall speed(PRM) | |||
| 10 | 10 | 1.1 | 0-3400 | 0.37 | 0-60 | 1200×600×1300 |
| 20 | 20 | 1.5 | 0.75 | 1500×800×1500 | ||
| 50 | 50 | 3 | 0.75 | 2750×2100×1900 | ||
| 100 | 100 | 3 | 1.5 | 2800×2150×2100 | ||
| 200 | 200 | 4 | 1.5 | 2850×2200×2200 | ||
| 300 | 300 | 5 | 2.2 | 3000×2600×2500 | ||
| 500 | 500 | 7.5 | 2.2 | 3800×2800×2700 | ||
| 750 | 750 | 11 | 3.7 | 3900×3900×2900 | ||
| 1000 | 1000 | 11 | 3.7 | 3900×3400×3150 | ||
| 2000 | 2000 | 22 | 7.5 | 4850×4300×3600 | ||
| We can customize the equipment according to customer requirements. | ||||||
Product Description of theVacuum Homogenizing Emulsifying Mixer:
China Manufacture Stainless Steel Vacuum Emulsion Mixer Chemical Homogenizer |
|||
Profile type |
Emulsifying Tank |
Oil Tank |
Water Tank |
material |
SS316L |
||
Volume |
20L-2000L (Customized) |
||
application |
Food, pharmaceutical industry, chemical industry, etc |
||
Working pressure |
Vacuum |
Normal Pressure |
Normal Pressure |
Surface |
Mirror, Ra<0.4μm |
||
Heating mode |
electric heating |
||
Agitator Type |
scraped wall mixer+emulsify mixer |
dispersing mixer |
dispersing mixer |
Mixer speed |
0-3400RPM/0-60RPM |
1400RPM |
1400RPM |
PARTS DETAILS |
1 .Vacuum Pump |
||
2 .control Box |
|||
3 .Various types of CIP cleaners |
|||
4 .Tilting type or vertical type |
|||
5 .Inlet and Outlet sanitary valve. |
|||
6 .Stainless steel platform |
|||
It’s used for produce the cream, lotion, paste, ointment, paste, conditioner, etc. Complex scraping board blending oar is suitable to every kind of complicated recipe and achieve optimizing effect;
Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;
Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During few production, it can exert homogenizing effect fully;
Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high-capability cut,rubbing,centrifugal to make sure exquisite and slick cream;
boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
Customer can choose frequency conversion timing homogenizer and highest rotate speed is 3400 r/min.
